V80H NiMH 1.2 V 80 mAh battery with solder tabs

SKU: BANM160SC1

V80H 1.2 V 80 mAh rechargeable NiMH button cell battery with two small solder tabs for memory backup, RTC, CMOS, and PCB electronic assembly.

Price:
Sale price5,80 €

Tax included Shipping calculated at checkout

Stock:
In stock

If you have not found your product or model, please contact us via this form . We will do our best to help you.

🚚 En stock en France – Expédition sous 24 à 48 h

📞 Need help? An expert will answer you 09 73 88 22 81

📩 Can't find your model? Contact us via this form: we will help you identify the right model quickly.

MAIN REFERENCE
V80H
80H
V80-H

RELATED REFERENCES
Varta V80H
Varta V60H
Varta V60R
Varta V60RT
Varta V70H
Varta 55608101501
Varta V80H-SLF
GP GP80BVH
Emmerich ZA65

TECHNOLOGY
Rechargeable NiMH

VOLTAGE
1.2 V

CAPACITY
80 mAh

APPLICATIONS
Memory backup
RTC clock
BIOS / CMOS
Electronic board
PCB / IC assembly
Measuring equipment
Embedded system

TERMINATION
2 small solder tabs
Tabs oriented in the same direction

IMPORTANT
Always check the dimensions, tab layout, spacing, and polarity before ordering.

Description

V80H NiMH 1.2 V 80 mAh Battery with Solder Tabs

The V80H battery is a small rechargeable NiMH button cell designed for electronic assemblies requiring a compact backup power supply. It delivers a nominal voltage of 1.2 V with a capacity of 80 mAh and is particularly suitable for low-power circuits.

This version features two small metal solder tabs. They are oriented in the same direction to allow integration into certain printed circuit boards and specific electronic assemblies.

Technical specifications

  • Technology: Rechargeable NiMH
  • Nominal voltage: 1.2 V
  • Capacity: 80 mAh
  • Nominal energy: 0.096 Wh
  • Format: V80H / 80H
  • Diameter: approximately 15.5 mm
  • Height: approximately 6 to 6.4 mm excluding tabs, depending on the manufacturer
  • Connection: two small solder tabs
  • Rechargeable: yes

80mAh button cell for electronic backup

This 80mAh button cell is particularly suitable for backing up information when the main equipment is no longer powered. It can be used for RTC clocks, BIOS, CMOS, electronic memories, measuring devices, and various embedded equipment.

Its very compact format allows it to be installed on boards with limited space. However, an 80mAh button cell must maintain the technology and voltage specified by the original charging circuit.

V80H solder battery: check the tabs

A V80H solder battery may come in different connection styles. Therefore, before ordering, carefully compare the removed cell with the product offered.

In particular, check the position of the two tabs, their width, their length, and their polarity. This V80H solder battery is suitable when the two small tabs are oriented in the same direction as on the existing assembly.

Compatible references and replacements

The V80H battery is also known by the designations 80H and V80-H. Some older V60H, V60R, V60RT, or V70H cells can be replaced by a V80H when the dimensions and charging circuit match.

Similar references are also available from GP and Emmerich. However, the capacity or termination may vary depending on the manufacturer. A mechanical check remains essential.

Use and maintenance

Observe the polarity during assembly and exclusively use the tabs designed for soldering. Avoid heating the body of the rechargeable cell directly and use only a charging system designed for NiMH technology.

You can also find our selection of NiMH batteries for assembly. To learn more about this technology, also consult the Varta technical documentation on NiMH cells.

Warranty and shipping

New product, inspected before shipping. Stock in France when available. Shipping within 24 to 48 hours.
